| 品牌：3PEAK思瑞浦 | 型号：LM2904A-SR | 类型：放大器 |
| 用途：电脑 | 封装：SOP8 | 批号：24+ |
| 应用领域：3C数码 |
The LM2904A/2902A series amplifiers are newest high supply voltage amplifiers with low offset, low power and stable frequency response. They incorporate 3PEAK’s proprietary and patented design techniques to achieve very good AC performance with 0.9MHz bandwidth, 0.5V/μs slew rate and maximum 3mV offset while drawing only 100μA of quiescent current per amplifier. The input common-mode voltage range extends to V–, and the outputs swing rail-to-rail. The LM2904A/2902A family can be used as plug-in replacements for many commercially available op-amps to reduce power and improve input/output range and performance.
The combination of features makes the LM2904A/2902A ideal choices for power module, industrial control, motor control and audio application.
Features：
Supply Voltage: 3V to 36V
Low Supply Current: 100μA per channel
Input Common-Mode Voltage Range Includes Ground
Can Work as Comparator
Rail to Rail Output
Bandwidth: 0.9 MHz
Slew Rate: 0.5V/μs
Excellent EMI Suppress Performance: 71dB at 1GHz
Offset Voltage: ±3mV Maximum
Offset Voltage Temperature Drift: 7 μV/°C
–40°C to 125°C Operation Temperature Range
Applications：
Power Module
Sensor Interface
Motor Control
Audio
